  • Abrasion Resistance

    The resistance to scratching of a surface of paper by other paper surfaces or other materials.

  • Absorbency

    The ability of a material to take up moisture

  • Accordion Fold

    A type of paper folding in which each fold runs in the opposite direction to the previous fold creating a pleated or accordion effect.

  • Acid Resist

    An acid-proof protective coating applied to metal plates prior to etching designs thereon. Bichromated solutions employed in photoengraving as sensitizers provide acid resist through the action of light on sensitized surface.

  • Acrylic

    A water-soluble polymer used in paints to make them dry both tough and flexible.

  • Actinic Rays

    Light exposure that affects chemical changes in paper.

  • Additive Colors

    In photographic reproduction, the primary colors of red, green and blue which are mixed to form all other colors.

  • Aerate

    This refers to a manual process whereby an air stream is blown onto paper sheets to create a riffling effect that separates the sheets as they are fed to the printing press.

  • Agate

    A type size of 5 1/2 points. Reference, agate line.

  • Agate Line

    In newspaper classifieds, a measurement denoting 1/4 inch depth by one column width. 14 agate lines = one column inch.

  • Air

    Large white areas in a design layout.

  • Airbrush

    A compressed air tool that dispenses a fine mist of paint or ink; used in illustration and photo retouching.

  • Albion Press

    A hand operated printing press made of iron.

  • Album Paper

    A wood pulp paper with an antique finish used for pages of photo albums.

  • Albumen Plate

    A surface plate used in the lithography process; it has a photosensitive coating.

  • Albumin Paper

    A coated paper used in photography; the coating is made of albumen (egg whites) and ammonium chloride.

  • Alignment

    The condition of type and or art materials as they level up on a horizontal or vertical line.

  • Alkali Blue

    Also called reflex blue. A pigment used in carbon black inks and varnishes to improve luster.

  • Alley

    A term for a random, coincidental path or a row of white space within a segment of copy.

  • Alphabet Length

    The measured length (in points) of the lowercase alphabet of a certain size and series of type.

  • Amberlith

    Red-orange acetate used for masking mechanicals when photographing for plates. The amberlith area appears black to the camera, and prints clear on the resulting film.

  • American Paper Institute

    An organization that correlates all paper related information.

  • Angle Bar

    In "web-fed" printing (printing on rolls of paper as opposed to single sheets), an angle bar is a metal bar that is used to turn paper between two components of the press.

  • Aniline

    Oil-based solvent (quick drying) used in the preparation process of dyes and inks.

  • Animal Sized

    A technique of paper making which hardens the surface by passing the paper through a bath of animal glue or gelatin.

  • Anodized Plate

    In lithography, a plate manufactured with a barrier of aluminum oxide, which prevents chemical reactions that break down the plate; it provides optimum press performance.

  • Antigua

    An eleventh century Italian script typeface.

  • Antiquarian

    A handmade paper (53 x 31 inches), largest known handmade paper.

  • Antique Finish

    Paper with a rough, sized surface used for book and cover stock.

  • Antiskinning Agent

    An antioxidant agent used to prevent inks from skinning over in the can.

  • Apron

    The white area of text (or illustrations) at the margins which form a foldout.

  • Aqua Tint

    A printing process that uses the recessed areas of the plate; ideal for graded and even tones.

  • Aquarelle

    The hand application of color, through stencils onto a printed picture.

  • Aqueous Plate

    Water soluble plate coatings, which are less toxic and less polluting.

  • Arc Light

    A light source produced by the passing of electric current between two electrodes; used in the production of plates in photolithography.

  • Arms

    Those elements of letters that branch out from the stem of a letter, such as: "K" and "Y".

  • Arrowhead

    A symbol shaped like an arrowhead that is used in illustration to direct a leader line. Reference, leader line

  • Art Paper

    A paper evenly coated with a fine clay compound, which creates a hard smooth surface on one or both sides.

  • Art Work

    Any materials or images that are prepared for graphic reproduction.

  • Art-Lined Envelope

    An envelope that is lined with an extra fine paper; can be colored or patterned.

  • Artwork

    All illustrated material, ornamentation, photos and charts etc., that is prepared for reproduction.

  • As To Press

    In gravure printing, (recessed areas of plate hold ink), a term used for proofs showing the final position of color images.

  • ASA

    A number set by the American Standards Assoc., which is placed on film stock to allow calculation of the length and "F" number of an exposure. Reference, "F" numbers.

  • Ascender

    Any part of a lower case letter which rises above the main body of the letter such as in "d", "b" and "h".

  • Assembled negative

    Film negatives consisting of line and halftone copy which are used to make plates for printing.

  • Assembled view

    In illustration, a term used to describe a view of a drawing in its assembled or whole format.

  • Author's Alterations (AA's)

    Changes made after composition stage where customer is responsible for additional charges.

  • Autochrome paper

    Coated papers that are regarded as exceptional for multi-colored printing jobs.

  • Autolithography

    A printing method whereby the image is hand drawn or etched directly onto lithography plates or stones.

  • Autopositive

    Any photo materials which provide positive images without a negative.

  • Azure

    The light blue color used in the nomenclature of "laid" and "wove" papers.

  • Back Lining

    The fixing of a material, either paper or cloth, to the back of a book before it is bound. Reference: case binding.

  • Back Margin

    A term referring to the margin which lies closest to the back of the book.

  • Back Step Collation

    The collation of book signatures according to reference marks which are printed on the back fold of each section.

  • Back To Back

    Print applied to both sides of a sheet of paper.

  • Backbone

    That portion of the binding, which connects the front of the book with the back of the book; also called "back".

  • Background

    That portion of a photograph or line art drawing that appears furthest from the eye; the surface upon which the main image is superimposed.

  • Backslant

    Any type that tilts to the left or backward direction; opposite of italic type.

  • Backstep Marks

    Marks printed on signatures that indicate where the final fold will occur. When gathering and initial folding is completed, these marks appear as a stepped sequence.

  • Baking

    A term given to the procedure of drying coatings onto papers.

  • Balance

    A term used to describe the aesthetic or harmony of elements, whether they are photos, art or copy, within a layout or design.

  • Balloon

    In an illustration, any line which encircles copy, or dialogue.

  • Bank Paper

    A thin uncoated stock used for making carbon copies.

  • Banker's Flap Envelope

    Also called wallet flap; the wallet flap has more rounded flap edges.

  • Banner

    The primary headline usually spanning the entire width of a page.

  • Barn Doors

    A device with two sets of thin metal doors (horizontal and vertical) placed before a light source to control the direction of light.

  • Barrier Coat

    A coating that is applied onto the non-printing side of paper to add to the opacity of that paper. Reference, opacity.

  • Baryta Paper

    A coated stock (barium sulfate compound) used for text impressions on typesetting machines.

  • Bas Relief

    A three dimensional impression is which the image stands just slightly out from the flat background. References, blind emboss.

  • Base

    The support onto which printing plates is fixed.

  • Base Film

    The foundation material onto which the film positives are stripped for making printing plates. Reference, photomechanical.

  • Base Line

    This is a term used to describe the imaginary horizontal line upon which stand capitals, lower case letters, punctuation points etc.

  • Basic Size

    This term refers to a standard size of paper stock; even though the required size may be smaller or larger.

  • Basis Weight

    Basis or basic weight refers to the weight, in pounds, of a ream (500 sheets) of paper cut to a given standard size for that particular paper grade.

  • Bauhaus

    A design school in Germany where the Sans Serif font was originated.

  • Bearoff

    The adjusting of spacing of type in order to correct the justification.

  • Bed

    The steel flat table of a cylinder printing press upon which the type sits during the printing process.

  • Bending Chip

    A recycled paperboard product used for making folding cartons.

  • BF

    An abbreviation for boldface, used to determine where boldface copy is to be used. Reference, boldface.

  • Bible Paper

    A thin but strong paper (opaque), used for Bibles and books.

  • Bimetal Plate

    A plate which is used in long print runs; the printing image is copper or brass, and the non-printing area is aluminum or stainless steel.

  • Binder's Board

    A heavy paperboard with a cloth covering that is used for hardback binding of books.

  • Binding

    Various methods of securing folded sections together and or fastening them to a cover, to form single copies of a book.

  • Bite

    The etching process in photoengraving requires the application of an acid; the length of time this acid is left to etch out an image is referred to as its bite. The more bites, the deeper the etched area.

  • Black Letter

    An old style of typeface used in Germany in the 15th century, also referred to as Old English (US) and Gothic (UK).

  • Black Out

    Also referred to as black patch; a piece of masking material which is used in layout to mask an area leaving a window into which another element can be stripped.

  • Black Photo Paper

    A black paper used to protect photosensitive materials.

  • Black Printer

    Refers to the film portion of the color separation process that prints black; increases the contrast of neutral tones.

  • Blackening

    Darkening a portion of a sheet of paper due to the excessive pressure of the calendar roll. Reference, calendar.

  • Blanket

    On offset presses a fabric-reinforced sheet of rubber to transfer the impression from the plate onto the paper.

  • Blanket To Blanket Press

    A printing method in which there are two blanket cylinders through which a sheet of paper is passed and printed on both sides.

  • Bleed

    Extra ink area that crosses trim line, used to allow for variations that occur when the reproduction is trimmed or die-cut.

  • Blind Emboss

    A design or bas relief impression that is made without using inks or metal foils.

  • Blind Embossing

    Embossed forms that are not inked, or gold leafed.

  • Blind Folio

    Page number not printed on page.

  • Blind Image

    A problem that arises in the lithography process when an image loses its ink receptivity and fails to print.

  • Blistering

    Although seemingly dry, paper does contain approximately 5% moisture. In cases where there is excessive moisture, and the paper is passed through a high heat-drying chamber, the moisture within the paper actually boils and causes a bubble or blistering effect.

  • Block

    Illustrations or line art etched onto zinc or copper plates and used in letterpress printing.

  • Block In

    To sketch the primary areas and points of reference of an illustration in preparation for going to final design or production.

  • Block Resistance

    The resistance of coated papers to blocking. Reference, blocking.

  • Blocking

    The adhesion of one coated sheet to another, causing paper tears or particles of the coating to shed away from the paper surface.

  • Blocking Out

    To mask a section of an art layout before reproduction.

  • Blow-up

    Any enlargement of photos, copies or line art.

  • Blue-Line

    Photographic proof made from flats for checking accuracy, layout and imposition before plates are made. Also known as a dylux.

  • Body

    The main shank or portion of the letter character other than the ascenders and descenders. Also: A term used to define the thickness or viscosity of printer's ink.

  • Body Size

    The point size of a particular type character.

  • Boiler Plate

    Repetitive blocks of type that are picked up and included routinely without recreating them.

  • Boldface

    Any type that has a heavier black stroke that makes it more conspicuous.

  • Bolts

    The edges of folded sheets of paper, which are trimmed off in the final stages of production.

  • Bond

    A grade of durable writing, printing and typing paper that has a standard size of 17x22 inches.

  • Book

    A general classification to describe papers used to print books; its standard size is 25x38 inches. A printed work which contains more than 64 pages.

  • Book Block

    A term given the unfinished stage of bookmaking when the pages are folded, gathered and stitched-in but not yet cover bound.

  • Bounce 1

    A registration problem, usually on copiers, where the image appears to bounce back and forth. A bounce usually occurs in one direction depending on how the paper is passing through the machine. This is usually accented by card stock (especially if it's over the machine's spec). When a customer refuses a job for whatever reason.

  • Bourges

    A pressure sensitive color film that is used to prepare color art.

  • Box Cover Paper

    A lightweight paper used expressly for covering paper boxes.

  • Box Enamel Paper

    A glossy coated paper used to cover paper boxes.

  • Box Liners

    A coated paper used on the inside of boxes, which are used for food.

  • Brace

    A character " }" used to group lines, or phrases.

  • Break For Color

    In layout design, the term for dividing or separating the art and copy elements into single color paste-up sheets.

  • Bristol Board

    A board paper of various thickness; having a smooth finish and used for printing and drawing.

  • Broad Fold

    A term given to the fold whereby paper is folded with the short side running with the grain.

  • Brocade

    A heavily embossed paper.

  • Brochure

    A pamphlet that is bound in booklet form.

  • Bronzing

    A printing method whereby special ink is applied to sheets and then a powder is applied producing a metallic effect.

  • Brownline Proof

    A photographic proof made by exposing a flat to UV light creating a brown image on a white background. Also referred to as silverprint.

  • Buckle Folder

    A portion of the binding machinery with rollers that fold the paper.

  • Buckram

    A coarse sized cloth used in the bookbinding process.

  • Bulk

    A term used to define the number of pages per inch of a book relative to its given basis weight.

  • Bulk

    A term given to paper to describe its thickness relative to its weight.

  • Bullet

    A boldface square or dot used before a sentence to emphasize its importance.

  • Bump Exposure

    A process used in halftone photography that entails the temporary removal of the screen during exposure. This increases the highlight contrast and diminishes the dots in the whites.

  • Burn

    A term used in plate making to describe the amount of plate exposure time.

  • Burnish

    A term used for the process of "rubbing down" lines and dots on a printing plate, which darkens those rubbed areas.

  • Burnishing

    Creating a polished finish on paper by rubbing with stone or hand smoothing a surface.

  • Burst Binding

    A binding technique that entails nicking the backfold in short lengths during the folding process, which allows glue to reach each individual leaf and create a strong bond.

  • Cable Paper

    A strong paper used to wrap electrical cables.

  • Cadmium Yellow

    A pigment made from cadmium sulfide and cadmium selenide.

  • Calendar Board

    A strong paperboard used for calendars and displays.

  • Calendar Rolls

    A series of metal rolls at the end of a paper machine; when the paper is passed between these rolls it increases its smoothness and glossy surface.

  • Caliper

    The measurement of thickness of paper expressed in thousandths of an inch or mils.

  • Cameo

    A dull coated paper, which is particularly useful in reproducing halftones and engravings.

  • Camera Ready

    A term given to any copy, artwork etc., that is prepared for photographic reproduction.

  • Canvas Board

    A paperboard with a surface of simulated canvas, used for painting.

  • Carbonate Paper

    A chemical pulp paper (calcium carbonate), used mostly for the printing of magazines.

  • Cast Coated

    A paper that is coated and then pressure dried using a polished roller which imparts an enamel like hard gloss finish.

  • Coarse Screen

    Halftone screens commonly used in newsprint; up to 85 lines per inch.

  • Coated (Paper)

    Paper coated with clay, white pigments and a binder. Better for printing because there is less picking.

  • Coated Art Paper

    Printing papers used for printing projects that require a special treatment of detail and shading.

  • Collate

    To gather sheets or signatures together in their correct order. (see Gather)

  • Color Bars

    This term refers to a color test strip, which is printed on the waste portion of a press sheet. It is a standardized (GATF-Graphic Arts Technical Foundation) process which allows a pressman to determine the quality of the printed material relative to ink density, registration, and dot gain. It also includes the Star Target, which is a similar system designed to detect inking problems.

  • Color Separating

    The processes of separating the primary color components for printing.

  • Color Strength

    A term referring to the relative amount of pigmentation in an ink.

  • Color Transparency

    Transparent film containing a positive photographic color image.

  • Composition

    The assembly of characters into words, lines and paragraphs of text or body matter for reproduction by printing.

  • Condensed Type

    A narrow, elongated type face.

  • Continuous Tone

    Image made of non-discernable picture elements which give appearance of continuous spectrum of grey values or tones.

  • Contrast

    The degree of tonal separation or gradation in the range from black to white.

  • Contre Jour

    Taking a picture with the camera lens facing the light source.

  • Copy

    Refers to any typewritten material, art, photos etc., to be used for the printing process.

  • Copyboard

    A board upon which the copy is pasted for the purpose of photographing.

  • Corner Marks

    Marks on a final printed sheet that indicate the trim lines or register indicators.

  • Cover

    A term describing a general type of papers used for the covers of books, pamphlets etc.

  • Cracking

    Delamination.

  • Creep

    When the rubber blanket on a cylinder moves forward due to contact with the plate or paper. Result of added thickness of folded sheets being behind one another in a folded signature. Outer edges of sheets creep away from back most fold as more folded sheets are inserted inside the middle.

  • Crop

    To eliminate a portion of the art or copy as indicated by crop marks.

  • Crop Mark

    Markings at edges of original or on guide sheet to indicate the area desired in reproduction with negative or plate trimmed (cropped) at the markings.

  • Cross-over

    Elements that cross page boundaries and land on two consecutive pages (usually rules).

  • Crossmarks

    Marks of fine lines, which intersect to indicate accurate alignment of art elements.

  • Crossover

    A term used to describe the effect of ink from an image, rule or line art on one printed page, which carries over to another page of a bound work.

  • CTP

    see Computer to Plate

  • Curl

    Not lying flat and tending to form into cylindrical or wavy shapes. A term to describe the differences of either side of a sheet relative to coatings, absorbency etc.; the concave side is the curl side.

  • Cut-off

    A term used in web press printing to describe the point at which a sheet of paper is cut from the roll; usually this dimension is equal to the circumference of the cylinder.

  • Cutter

    Machine for accurately cutting stacks of paper to desired dimensions...can also be used to crease. Also trims out final bound books' top size (soft cover).

  • Cutting Die

    Sharp edged device, usually made of steel, to cut paper, cardboard, etc., on a printing press.

  • Cyan

    A shade of blue used in the four-color process; it reflects blue and green and absorbs red.

  • Cylinder Gap

    The gap in the cylinders of a press where the grippers or blanket clamps is housed.

  • Dahlgren

    A dampening system for printing presses which utilizes more alcohol (25%) and less water; this greatly reduces the amount of paper that is spoiled.

  • Dampening

    An essential part of the printing process whereby cloth covered rubber rollers distributes the dampening solution to the plate.

  • Dandy Roll

    During the paper making process while the paper is still 90% water, it passes over a wire mesh cylinder (dandy roll), which imparts surface textures on the paper such as wove or laid. This is also the stage where the watermark is put onto the paper.

  • Deckle Edge

    The rough or feathered edge of paper when left untrimmed.

  • Deep Etching

    The etching or removal of any unwanted areas of a plate to create more air or white space on the finished product.

  • Delete

    An instruction given to remove an element from a layout.

  • Demy

    A term that describes a standard sized printing paper measuring 17.5 x 22.5 in.

  • Densitometer

    An optical device used by printers and photographers to measure and control the density of color.

  • Density

    The lay of paper fibers relative to tightness or looseness which affects the bulk, the absorbency and the finish of the paper.

  • Density

    The degree of tone, weight of darkness or color within a photo or reproduction; measurable by the densitometer. Reference, densitometer.

  • Descender

    A term that describes that portion of lower case letters which extends below the main body of the letter, as in "p".

  • Diazo

    A light sensitive coal tar product used as a coating on presensitized plates, as well as overlay proofs.

  • Die

    Design, letters or shapes, cut into metal (mostly brass) for stamping book covers or embossing. An engraved stamp used for impressing an image or design.

  • Die Cutting

    A method of using sharp steel ruled stamps or rollers to cut various shapes i.e. labels, boxes, image shapes, either post press or in line. The process of cutting paper in a shape or design by the use of a wooden die or block in which are positioned steel rules in the shape of the desired pattern.

  • Die Stamping

    An intaglio process for printing from images engraved into copper or steel plates.

  • Digital Proof

    Color separation data is digitally stored and then exposed to color photographic paper creating a picture of the final product before it is actually printed.

  • Dimensional stability

    The qualities of paper to stabilize its original size when undergoing pressure or exposed to moisture.

  • Diploma

    A fine paper made specifically for the printing of diplomas, certificates and documents.

  • Direct Screen Halftone

    A color separation process using a halftone negative made by direct contact with the halftone screen.

  • Direct to Plate

    see Computer to Plate

  • Display Type

    Any type that stands out from the rest of the type on a page which attracts attention of the reader.

  • Distribution Rollers

    In the printing process, the rubber coated rollers responsible for the distribution of ink from the fountain to the ink drum.

  • Doctor Blade

    A term in gravure printing which refers to the knife-edge that runs along the printing cylinder; its function is to wipe the excess ink away from the non-printing areas.

  • Dog Ear

    Occurs when you fold into a fold (such as a letter fold). At the side of one of the creases you get an indentation. It may look like a small inverted triangle.

  • Dot

    The smallest individual element of a halftone.

  • Dot Gain

    Darkening of halftone image due to ink absorption in paper causing halftone dots to enlarge. Terms to describe the occurrence whereby dots are printing larger than they should.

  • Draw-down

    A method used by ink makers to determine the color, quality and tone of ink. It entails the drawing of a spatula over a drop of ink, spreading it flat over the paper.

  • Drier

    A term that describes any additives to ink which encourages the drying process.

  • Drill

    The actual drilling of holes into paper for ring or comb binding.

  • Drop Folio

    Page number printed at foot of page.

  • Drop Shadow

    A shadow image placed strategically behind an image to create the affect of the image lifting off the page.

  • Dry Mount

    Pasting with heat sensitive adhesives.

  • Dry Offset

    Process in which a metal plate is etched to a depth of 0.15 mm (0.006 in), making a right-reading relief plate, printed on the offset blanket and then to the paper without the use of water.

  • Ductor Roller

    The roller between the inking and the dampening rollers.

  • Dull Finish

    Any matte finished paper.

  • Dummy

    A term used to describe the preliminary assemblage of copy and art elements to be reproduced in the desired finished product; also called a comp.

  • Dummy Model

    Resembling finished piece in every respect except that the pages and cover are blank, used by the designer as a final check on the appearance and +feel+ of the book as a guide for the size and position of elements on the jacket.

  • Duotone

    Color reproduction from monochrome original. Keyplate usually printed in dark color for detail, second plate printed in light flat tints. A two-color halftone reproduction generated from a one-color photo.

  • Duplex Paper

    Paper which has a different color or finish on each side.

  • Dutch

    Any deckle edged paper, originally produced in the Netherlands. Reference, deckle edge

  • Dye-Based Ink

    Any ink that acquires its color by the use of aniline pigments or dyes. Reference, aniline

  • Eggshell Finish

    The finish of paper surface that resembles an eggshell achieved by omitting the calendar process. Reference, calendar rolls.

  • Electronic Composition

    The assembly of characters into words, lines and paragraphs of text or body matter with graphic elements in page layout form in digital format for reproduction by printing.

  • Electronic Proof

    A process of generating a prepress proof in which paper is electronically exposed to the color separation negatives; the paper is passed through the electrically charged pigmented toners, which adhere electrostatically, resulting in the finished proof.

  • Elliptical Dot

    Halftone screens in which the dots are actually elongated to produce improved middle tones.

  • Em

    A unit of measurement equaling 12 points or 4.5mm.

  • Embossed

    A method of paper finishing whereby a pattern is pressed into the paper when it is dry.

  • Embossing

    To raise in relief a design or letters already printed on card stock or heavy paper by an uninked block or die. In rubber and plastic plate making the process is usually done by heat.

  • Emulsion

    A light sensitive substance used as a coating for film; made from a silver halide compound. This side should face the lens when the film is exposed.

  • Enamel

    A term that describes a glossy coating on paper.

  • Endsheet

    Attaching the final sheet of a signature of a book to the binding.

  • English Finish

    A grade of uncoated book paper with a smooth uniform surface.

  • Engraving

    A printing process whereby images such as copy or art are etched onto a plate. When ink is applied, these etched areas act as small wells to hold the ink; paper is forced against this die and the ink is lifted out of the etched areas creating raised images on the paper.

  • Estimate

    The form used by the printer to calculate the project for the print buyer. This form contains the basic parameters of the project including size, quantity, colors, bleeds, photos etc.

  • Estimator

    One who computes or approximates the cost of work to be done on which quotation may be based.

  • Etch

    The process of producing an image on a plate by the use of acid.

  • Even Smalls

    The use of smaller sized capitals at the beginning of a sentence without the use of larger sized caps.

  • Expanded Type

    Type with width greater than normal producing a rectangular effect.

  • Exposure

    That stage of the photographic process where the image is produced on the light sensitive coating.

  • Extender

    A white pigment added to a colored pigment to reduce its intensity and improve its working qualities.

  • F&G

    A term in the binding process referring to folding and gathering.

  • Fan Fold

    Paper folding that emulates an accordion or fan, the folds being alternating and parallel.

  • Fat Face

    Type that is quite varied in its use of very thin and very wide strokes.

  • Felt

    A cloth conveyor belt that receives papers from the Fourdrinier wire and delivers it to the drier.

  • Felt Finish

    The smoother side of paper, usually a soft weave pattern used for book papers.

  • Felt Side

    It is the top side of the sheet in the paper making process that does not lie on the Fourdrinier wire.

  • Filling In

    A fault in printing where the ink fills in the fine line or halftone dot areas.

  • Film Coat

    Also called wash coat; any thinly coated paper stock.

  • Finish

    The surface quality of paper.

  • Finish (Paper)

    Dull - (low gloss) also matte or matte gloss.

  • Fist

    A symbol used in printing to indicate the index; seen as a pointing finger on a hand "+".

  • Fit

    The registration of items within a given page.

  • Flash Point

    A term given to the lowest temperature of ignitibility of vapors given off by a substance.

  • Flat

    In lithography, the assembly of photographic negatives or positives on vinyl acetate for exposure in vacuum frame in contact with sensitized metal press plate.

  • Flock Paper

    Paper that is patterned by sizing, and than coated with powders of wool or cotton, (flock).

  • Fluid Ink

    Also called liquid ink; ink with a low viscosity.

  • Flush Cover

    A bound book or booklet etc. having the cover trimmed to the same size as the text.

  • Flushed Pigment

    The results of combining a wet ink pigment with a varnish and having the wet pigment mix or transfer over to the varnish.

  • Fogging Back

    Lowering density of an image in a specific area usually to make type more legible while still letting image show through.

  • Foils

    Papers that have a surface resembling metal.

  • Fold Marks

    Markings at top edges that show where folds should occur.

  • Folder

    Machine used to fold signatures down into sections.

  • Folio or Page Number

    Number of page at top or bottom either centered, flushed left or flushed right often with running headline.

  • Font

    The characters which make up a complete typeface and size.

  • Form Rollers

    The rollers that come into direct contact with the plate of a printing press.

  • Forme

    (old) type matter or type and block with its accompanying spacing material secured in the forme called a chase.

  • Forwarding

    In Binding, the process between folding sheets and casing in, such as rounding and backing, putting on headbands, reinforcing backs, etc.

  • Fourdrinier

    A machine with a copper wire screen that receives the pulp slurry in the paper making process which will become the final paper sheet.

  • Free sheet

    Any paper that is free from wood pulp impurities.

  • French Fold(er)

    Folder with printing on one side so that when folded once in each direction, the printing on outside of the folds.

  • Fringe

    A halo that appears around halftone dots.

  • Fugitive inks

    Colors that lose tone and permanency when exposed to light.

  • Furnish

    The slurry mixture of fibers, water, chemicals and pigments, that is delivered to the Fourdrinier machine in the paper making process.

  • Fuzz

    A term for the fibers that project from the paper surface.

  • Galley

    (old) flat oblong tray into which composed type matter is put and kept until made up into pages in the forme. Also a similar tray on a slug composing machine which receives the slugs as they are ejected. Also a long column of composed text matter

  • Galley Proof

    A proof of text copy before it is pasted into position for printing.

  • Galley Slave

    Old term for compositor.

  • Gang

    Group of frames or impositions in the same forme of different jobs arranged and positioned to be printed together.

  • Ganging

    The bundling of two or more different printing projects on the same sheet of paper.

  • Gather

    To assemble or collect sections into single copies of complete books for binding.

  • Gathering

    Assembling sheets of paper and signatures into their proper sequence; collating.

  • Ghosting

    Marring a print by the placement of an image of work printed on the reverse side which has interfered with its drying so that differences in the trapping frame colors or glass variations are apparent.

  • Ghosting

    Image which appears as a lighter area on a subsequent print due to local blanket depressions from previous image areas on a letterpress rotary machine as well as on an offset press.

  • Gigo

    Garbage in, garbage out.

  • Gilding

    Sticking on gold leaf to edges of books with a liquid agent and made permanent with burnishing tools.

  • Glassine

    A strong transparent paper.

  • Gloss Ink

    Quick drying oil based inks with low penetration qualities, used on coated stock.

  • Glyphic

    A carved as opposed to scripted typeface.

  • Goldenrod

    An orange colored paper with gridlines, used to assemble materials for exposure for platemaking.

  • Graduated Screen

    An area of image where halftone dots range continuously from one density to another.

  • Grain

    Direction of fibers in a sheet of paper governing paper properties such as increased size changes with relative humidity, across the grain, and better folding properties along the grain.

  • Grained Paper

    A paper embossed to resemble various textures, such as leather, alligator, wood, etc.

  • Gravure

    An intaglio or recessed printing process. The recessed areas are like wells that form the image as paper passes through.

  • Gripper

    A series of metal fingers that hold each sheet of paper as it passes through the various stages of the printing process.

  • Gripper Edge

    The grippers of the printing press move the paper through the press by holding onto the leading edge of the sheet; this edge is the gripper edge.

  • Groundwood

    Low cost papers such as newsprint made by the mechanical pulping process as opposed to chemical pulping and refining.

  • Gumming

    The application of gum arabic to the non printing areas of a plate.

  • Gutter

    Space between pages in the printing frame of a book, or inside margin towards the back or binding edge. The blank space or margin between the type page and the binding of a book.

  • Hairline register

    Printing registration that lies within the range of plus or minus one half row of dots. It is the thinnest of the standard printers' rules.

  • Halftone

    Tone graduated image composed of varying sized dots or lines, with equidistant centers.

  • Halftone Paper

    A high finish paper that is ideal for halftone printing.

  • Halftone Screen

    A sheet of film or glass containing ruled right-angled lines, used to translate the full tone of a photo to the halftone dot image required for printing.

  • Hard Dot

    The effect in a photograph where a dot has such a small degree of halation that the dot shows quite sharp.

  • Head Margin

    That space which lies between the top of the printed copy and the trimmed edge.

  • Hickies

    Imperfections in presswork due to dirt on press, trapping errors, etc.

  • High Bulk Paper

    Paper stock that is comparatively thick in relation to its basis weight.

  • High Key Halftone

    A halftone that is made utilizing only the highlight tones down through the middle tones.

  • Highlight Dot

    The highest density of a halftone image.

  • Highlights

    The lightest tones of a photo, printed halftone or illustration. In the finished halftone, these highlights are represented by the finest dots.

  • Hollow

    That space on the spine of a case bound book between the block of the book and the case binding.

  • Hot melt

    An adhesive used in the binding process, which requires heat for application.

  • House Sheet

    This is a term that refers to a paper that a printer keeps on hand in his shop.

  • IBC

    Inside back cover.

  • IFC

    Inside front cover.

  • Image Area

    That portion of the printing plate that carries the ink and prints on paper.

  • Image Setter

    High resolution, large format device for producing film from electronically generated page layouts.

  • Imposition

    Arrangement of pages so that they print correctly on a press sheet, and the pages are in proper order when the sheets are folded.

  • Impression

    Product resulting from one cycle of printing machine. The pressure of the image carrier, whether it be the type, plate or blanket, when it contacts the paper.

  • Index Bristol

    A relatively thick paper stock; basis size---25 1/2 x 30 1/2.

  • Indicia

    Markings pre-printed on mailing envelopes to replace the stamp.

  • Industrial Papers

    A term used to denote papers such as janitorial, sanitary or heavy packing papers.

  • Ink Fountain

    The device which stores and meters ink to the inking rollers.

  • Ink Holdout

    A quality of paper to be resistant to ink absorption, allowing the ink to dry on the paper surface.

  • Ink Mist

    Any threads or filaments which protrude from the main printed letter body of long inks, as seen in newsprint.

  • Ink Setting

    The inertial resistance to flow that occurs to ink as soon as it is printed.

  • Inkometer

    A device used to measure the tack of ink.

  • Inserts

    Extra printed pages inserted loosely into printed pieces.

  • Integral Proof

    A proof made by exposing each of the four-color separations to an emulsion layer of primary colors. These emulsion sheets are stacked in register with a white sheet of paper in the background. Types of integral proofs are cromalin, matchprint, ektaflex, and spactraproof.

  • Interleaves

    Extra blank pages inserted loosely into book after printing.

  • Iridescent Paper

    A coated stock finished in mother-of-pearl.

  • Italic

    Text that is used to denote emphasis by slanting the type body forward.

  • Jacket

    The paper cover sometimes called the "dust cover" of a hardbound book.

  • Job Number

    A number assigned to a printing project used for record keeping and job tracking. Also used to retrieve old jobs for reprints or reworking by customer.

  • Jog

    To vibrate a stack of finished pages so that they are tightly aligned for final trimming.

  • Jogger

    Vibrating, sloping platform that evens up the edges of stacks of paper.

  • Kerning

    The narrowing of space between two letters so that they become closer and take up less space on the page.

  • Key Plate

    The printing plate that is used as a guide for the other plates in the color printing process; it usually has the most detail.

  • Keying

    The use of symbols, usually letters, to code copy that will appear on a dummy.

  • Keyline

    Lines that are drawn on artwork that indicate the exact placement, shape and size of elements including halftones, illustrations etc.

  • Kiss Impression

    A delicate printed impression, just heavy enough to be seen.

  • Kraft

    A coarse unbleached paper used for printing and industrial products.

  • Lacquer

    A clear gloss coating applied to printed material for strength, appearance and protection.

  • Laid Finish

    A parallel lined paper that has a handmade look.

  • Laser Engraving

    A paper cutting technique whereby laser technology is utilized to cut away certain unmasked areas of the paper. The cutting is a result of the exposure of the paper to the laser ray, which actually evaporates the paper.

  • Lay Edge

    Edge of a sheet of paper being fed into a printing press.

  • Layout

    A rendition that shows the placement of all the elements, roughs, thumbnails etc., of the final printed piece before it goes to print.

  • Leaders

    The dots or dashes used in type to guide the eye from one set of type to the next.

  • Leading

    Space between lines of type; the distance in points between one baseline and the next.

  • Leaf

    One of a number of folds (each containing two pages) which comprises a book or manuscript.

  • Leaf Stamping

    A metal die, either (flat, or embossed), created from the image or copy, which is then heated to a specific temperature which allows the transfer of a film of pigmented polyester to the paper.

  • Ledger Paper

    A stiff heavy business paper generally used for keeping records.

  • Length

    The optimum length of a filament of ink.

  • Letterpress

    Printing that utilizes inked raised surfaces to create the image.

  • Letterspacing

    The addition of space between typeset letters.

  • Line Copy

    Any copy that can be reproduced without the use of halftone screens.

  • Linen

    A paper that emulates the look and texture of linen cloth.

  • Lithocoated Paper

    A paper that is coated with a special water-resistant material which is able to withstand the lithographic process.

  • Lithography

    The process of printing that utilizes flat inked surfaces to create the printed images.

  • Logotype

    A personalized type or design symbol for a company or product.

  • M weight

    The actual weight of 1000 sheets of any given size of paper.

  • Machine Coated

    Paper that has had a coating applied to either one or two of its sides during the papermaking process.

  • Machine Direction

    An alternate term for grain direction.

  • Machine Finish

    A paper finish that results from the interaction of the paper with the Fourdrinier process as opposed to post machine embossing. Reference, Fourdrinier

  • Magnetic Black

    Black pigments containing black iron oxides, used for magnetic ink character recognition.

  • Make Rready

    Process of adjusting final plate on the press to fine tune or modify plate surface.

  • Margin

    Imprinted space around edge of page.

  • Mark-up

    To write up instructions, as on a dummy.

  • Mask (1)

    The blocking out of a portion of the printing plate during the exposure process.

  • Mask (2)

    A photo negative or positive used in the color separation process to color correct. Reference, PRINTING, mask.

  • Match Print

    Photographic proof made from all color flats and form composite proof showing color quality as well as accuracy, layout, and imposition before plates are made.

  • Matte Finish

    A coated paper finish that goes through minimal calendaring. Reference, calendaring.

  • Measure

    The width of type as measured in picas. Reference, picas.

  • Mechanical

    A term used to describe finished artwork that is camera ready for reproduction, including all type, photos, illustrations etc.

  • Metropolitan Service Area

    A group of ZIP codes usually in close proximity defining a large metropolitan area (e.g. New York City or Los Angeles).

  • Midtone Dot

    Commonly taken as the area between highlight and shadow area of a subject's face in halftone image.

  • Moire

    An undesirable halftone pattern produced by the incorrect angles of overprinting halftone screens.

  • Molleton

    A cotton fabric used on the dampening rollers of a printing press.

  • Molybdate Orange

    An ink pigment made from precipitating lead molybdate, lead sulfate and lead chromate.

  • Mottle

    A term used to describe spotty or uneven ink absorption.

  • Offset

    The most commonly used printing method, whereby the printed material does not receive the ink directly from the printing plate but from an intermediary cylinder called a blanket which receives the ink from the plate and transfers it to the paper.

  • Offset Paper

    A term for uncoated book paper.

  • Over Run

    Surplus of copies printed.

  • Parent Sheet

    A sheet that is larger than the cut stock of the same paper.

  • Perfect Binding

    Binding process where backs of sections are cut off, roughened and glued together, and rung in a cover.

  • Perfecting

    Printing both sides of the paper (or other material) on the same pass through the printing machine.

  • Perforating

    Punching small holes or slits in a sheet of paper or cardboard to facilitate tearing along a desired line.

  • Pin Register

    Using metal pins fitted into preset holes of copy sheets, films, plates and presses that will assure the proper registration.

  • Plate

    Reproduction of type or cuts in metal, plastic, rubber, or other material, to form a plate bearing a relief, planographic or intaglio printing surface.

  • Platemaking

    Making a printing plate from a film or flat including preparation of the plate surface, sensitizing, exposing through the flat, developing or processing, and finishing.

  • Point

    A measurement unit equal to 1/72 of an inch. 12 points to a pica, 72 points to an inch.

  • Ppi

    Pixels per inch.

  • Press-Proof

    Actual press sheet to show image, tone values and colors as well as imposition of frame or press-plate.

  • Process Inks

    Printing inks, usually in sets of four colors. The most frequent combination is yellow, magenta, cyan, and black, which are printed, one over another in that order, to obtain a colored print with the desired hues, whites, blacks, and grays.

  • Register

    The arrangement of two or more images in exact alignment with each other.

  • Register Marks

    Any crossmarks or other symbols used on layout to assure proper registration.

  • Saddle Stitching

    Stitching where the wire staples pass through the spine from the outside and are clinched in the center. Only used with folded sections, either single sections or two or more sections inset to form a single section.

  • Satin Finish

    A smooth delicately embossed finished paper with sheen.

  • Score

    Impressions or cuts in flat material to facilitate bending or tearing.

  • Screen Angles

    The placement of halftone screens to avoid unwanted moire patterns. Frequently used angles are black 45deg, magenta 75deg, yellow 90deg, and cyan 105deg.

  • Self Cover

    A cover made out of the same paper stock as the internal sheets.

  • Sheetwise

    The printing of two different images on two different sides of a sheet of paper by turning the page over after the first side is printed and using the same gripper and side guides.

  • Signature (Section)

    Printed sheet (or its flat) that consists of a number of pages of a book, placed so that they will fold and bind together as a section of a book. The printed sheet after folding.

  • Spine

    Back edge of a book.

  • Spiral Bind

    A binding whereby a wire or plastic is spiraled through holes punched along the binding side.

  • Spot Color

    Small area printed in a second color.

  • Synthetic Papers

    Any petroleum based waterproof papers with a high tensile strength.

  • Text

    A high quality printing paper.

  • Thermography

    A printing process whereby slow drying ink is applied to paper and while the ink is still wet, it is lightly dusted with a resinous powder. The paper then passes through a heat chamber where the powder melts and fuses with the ink to produce a raised surface.

  • Tint

    A halftone screen that contains all the same sized dots.

  • Transparent

    Inks that do not block out the colored inks that they print over, but instead blend with them to create intermediate colors.

  • Trapping

    The process of printing wet ink over printed ink which may be wet or dry.

  • Trim Marks

    Marks placed on the sheet to indicate where to cut the page.

  • Varnish

    A clear shiny ink used to add gloss to printed pieces. The primary component of the ink vehicle. Reference, vehicle.

  • W&T

    An abbreviation for work and turn.

  • Washup

    The procedure of cleaning a particular ink from all of the printing elements (rollers, plate, ink fountain etc.) of a press.

  • Watermark

    A translucent logo that is embossed during the papermaking process while the paper slurry is on the dandy roll. Reference, dandy roll

  • Web Press

    Cylinder printing machine in which the paper is fed from a continuous reel, as opposed to sheet fed.

  • Wet Trapping

    The ability of an ink film to accept subsequent ink films.

  • Wire Stitching Or Stapling

    To fasten together sheets, signatures, or sections with wire staples. 3 methods... saddle stitching, side stitching, and stabbing.
